StampaJet
BP-64
NEW !!!
DIGITAL
TEXTILE PRINTING MADE EASY -
|
Download PDF |
StampaJet
textile digital printing made easy
StampaJet
BP-64
- Digital Fabric Printing Made Easy
StampaJet BP64 a new generation
low cost textile printer, utilizing an all in one fabric transport system
and curing station, designed for digital fabric printers who require easy
to use equipment, high print speeds and exceptional quality. The
StampaJet
BP-64 with its integrated, ink and fabric versatility and exceptional
color control, combined with a competitive price and small footprint opens
new opportunities to textile digital printing.
Download PDF
188
ft2/h Plug & Print Digital Textile Printer
Digital textile printing is finally made easy thanks to the
StampaJet
top quality print results at production speeds of 12.5 linear yards per
hour*. The machine requires minimal assembly and ships with our proven
Evolution RIP ® software which makes fabric printing simple and
repeatable. Just connect the electric power, load the inks and go.
*Depending on color number, resolution and pass - see the production table
on the back side of the brochure.
New
Print Head Providing Speed, Versatility and Quality
The
StampaJet BP-64
comes with the new extra wide 8 channel variable dot Epson print head
addressable to 1440 DPI. The distance from the print heads and the fabric
surface is manually adjustable. On board cleaning and maintenance provides
quick and easy head cleaning to keep you up and running.
Integrated Fabric Handling and Curing System
The fabric transportation system allows users to load fabric
print and cure without the time or labor for a two step process. A
precision winding unwind mechanism moves fabric precisely and smoothly
through the curing system providing the correct amount of curing time.
StampaJet is
ideal to print on a wide variety of fabrics.
Winding and Unwinding System
StampaJet BP-64 allows for large
roll up to 220lb to be loaded on in order to give a user the ability to do
large unattended runs.
Hot Air Curing Dryers
StampaJet BP-64
utilizes hot air curing in a self contained chamber and ships with an air
cleaning system. Loading fabric into the dryer is hands free providing a
user piece of mind that they cannot get burned. The curing chamber is
digitally controlled for optimal working temperature and speed.
Bulk Ink Supply System
The
StampaJet BP-64
can print with disperse and pigment and sublimation inks via a refillable
bulk ink feed system.
|
|
MODEL |
StampaJet |
|
PRINTER |
Variable dot piezo
print heads |
|
Print heads -
COLORS |
1 extra wide 1440 nozzles piezo print heads
Each head 8 colors, 8 x180 nozzle rows |
|
Print heads level |
Manual
print head level adjustment for different media thickness |
|
Print head
cleaning |
Automatic print head
cleaning cycle |
|
PRINT RESOLUTIONS
|
540 - 720 - 900 - 1080 - 1440 dpi a 4,6,8,12,16 pass -
Unidirectional &
Bidirectional |
|
Fabric transport
|
Automatic roll unwind and rewind units,
with speed/tension control |
|
Print width, roll
size |
Maximum print width: 161 cm (63,3”) - maximum fabric roll
diameter: 28 cm. ( 11”) |
|
Print speed |
4 Colors -
540 x 720 dpi, 4 pass, bidirectional, 188 ft2/h or 12.6 linear yd/h
6/8 Colors - 540 x 720 dpi, 6 pass, bidirectional, 97 ft2/h or 6.5
linear yd/h
4 Colors - 540 x 1080 dpi, 6 pass, bidirectional, 128 ft2/h or 8.5
linear yd/h
6/8 Colors - 540 x 1080 dpi, 12 pass, bidirectional, 66 ft2/h or 4.4
linear yd/h |
|
Ink feed system |
Ink feed
system 2 x 4 or 1 x 8; Refillable ink cartridges |
|
Inks |
Disperse, Pigments,
Sublimation 4 colors or
8 colors |
|
Interface |
USB 2.0 |
|
Noise level
|
50 dB - 70dB ( printer only - does not
include exhaust ) |
|
Dimensions |
Width:
102” - Depth: 34” - Height: 67” Weight: 950 lbs |
|
Electric supply |
Printer: AC120V - 240V - 50/60Hz
Curing Unit : AC 220-240V - 50/60Hz - 30Amp installed power - working
power may be lower |
|
Working environment |
Temperature range: 20-35 °C
/ 68-95 °F - Humidity 35%-65% rh |
Download PDF
|
|
